BG Electrical White Touch LED Dimmer Master Euro Module EMTDMW
Original price
£20.00
-
Original price
£20.00
Original price
£20.00
£20.00
-
£20.00
Current price
£20.00
Ex VAT £16.67
Product Description
The EMTDMW is a white master touch LED dimmer from the BG Electrical Euro Module range. It is a master module for one-way control or use with a compatible secondary module for two-way control. Its trailing-edge electronic control supports compatible LED, dimmable CFL, halogen and incandescent lamps.
Key Features
- 5-100W dimmable LED load
- Soft start, silent operation and overload protection
- Touch control with smooth dimming
- Clips into compatible BG Euro Module front plates
- Minimum 25mm mounting box depth
Product Details & Specifications
Dimensions
Height
50 mm
Width
25 mm
Depth
25.9 mm
Product Details
SKU
EMTDMW
Manufacturer
BG Electrical
Range
Euro Module
Product Type
Touch LED Dimmer Master
Colour
White
IP Rating
IP20
Electrical Details
Dimmer Type
Trailing Edge
Operating Voltage
220-240 V AC
Dimmable LED Load
5-100 W
Tungsten / Incandescent Load
5-200 W
Halogen Load
20-200 W
Terminal Capacity
3 x 1 mm², 2 x 1.5 mm² or 1 x 2.5 mm²
Installation
Minimum Back Box Depth
25 mm
Compliance and Warranty
Standard
BS EN 60669-2-1
RS Electrical Supplies Warranty
1 Year
Manufacturer Warranty
25 Years (held directly with BG Electrical)
